PE/PP Needle Liquid Filter Bags For Liquid Filtration

PE/PP Needle Liquid Filter Bags For Liquid Filtration

PE/PP Needle Liquid Filter Bags For Liquid Filtration
PE/PP Needle Liquid Filter Bags For Liquid FiltrationPE/PP Needle Liquid Filter Bags For Liquid FiltrationPE/PP Needle Liquid Filter Bags For Liquid FiltrationPE/PP Needle Liquid Filter Bags For Liquid FiltrationPE/PP Needle Liquid Filter Bags For Liquid Filtration
CategoriesLiquid filter Bag
AlbumView larger image
BrandKTMT
MaterialPE, PP, Nylon
Temperature< 80-160°C
Filter Rating1μm,2μm,5μm,10μm,15μm,25μm etc
Ring ModelSS316,SS304,plastic,Zinc Coated
Processing WaySewing/weld/Welded top and Sewing Bottom, Sewing top/Welded Bottom
Top Ring StylesPP Ring, Galvanize O-Ring,SUS O-Ring, other customized styles
Top Ring MaterialsPolypropylene, Polyester, Nylon, Metal, SUS
Effective filtration areavarious specifications
FOB portTianjin, China
Terms of PaymentL/C, Western Union, T/T, Paypal
Update Time2019-03-22
Detail Information

                                        PE/PP Needle Liquid Filter Bags For Liquid Filtration

Introduction:



We are professional manufacturer of filter needle felt bags and dust filter bags. Over 10 years filtration solution experience makes us a sought-after partner with whom demanding customers can collaborate in an atmosphere of trust and confidence.



Specification:



Item

liquid filter bag

Type

Various specifications

Material

PE , PP , Nylon

Relative filtration pore size

0.2,0.5, 1,5, 10, 25, 50, 100, 200 ,300...1000µm

Temperature

 < 80-160°C

Bag top ring

Plastic(PP/PE)/stainless steel/zinc steel

Body construction

Sewn / welded

Type of bottom

Round / V triangle

Effective filtration area

Various specifications

Special requirement of diameter and collar extension can be customized

Bag head: plastic
Sewing


International standard filter bag parameter:


Filter bag
model

Filter bag
area(m2)

Filter bag
Volume(Liter)

Filter bag
Diameter (Inch/cm )

Filter bag Length

(Inch/cm )

No.1

0.19

7.9

7/17.8

16/40.65

No.2

0.41

17.3

7/17.8

32/81.3

No.3

0.05

1.4

4/10.2

8.25/20.9

No.4

0.09

2.5

4/10.2

14/35.5

No.5

0.22

8.1

6/152

22/55.9



Fiber

Abrasion resistance

Weakly acid

Strongly acid

Weakly alkali

Strongly alkaly

Solvent

Temperature (°C)

PE

Very good

Very good

Good

Good

Poor

Good

130-150

Nylon

Excellent

General

Poor

Excellent

Excellent

Good

135-149

PP

very good

Excellent

Excellent

Excellent

Excellent

General

90-110




Nylon Material:

Features:



1.3D space inside of non-woven fibers, capture small particle directly, high efficiency, low cost, large capacity of dirty particles.

2. High temperature resistance ( 80-120 °C)

3. Micron rating: 0.5-300um

4. Excellent resistant to hydrolysis, acids and alkalis.

5. Smooth surface, more defined pore size and good air permeability

6. Lower fiber release, Lower density, High mechanical characteristics

Applications:



1. Paints & lacquer industry

2. Waste water treatment

3. Food industry

4. Chemical industry

5. Beer & wine industry
