4040 8040 4021 Reverse osmosis Membrane for Industrial Waste Water treatment

4040 8040 4021 Reverse osmosis Membrane for Industrial Waste Water treatment

4040 8040 4021 Reverse osmosis Membrane for Industrial Waste Water treatment
4040 8040 4021 Reverse osmosis Membrane for Industrial Waste Water treatment4040 8040 4021 Reverse osmosis Membrane for Industrial Waste Water treatment4040 8040 4021 Reverse osmosis Membrane for Industrial Waste Water treatment4040 8040 4021 Reverse osmosis Membrane for Industrial Waste Water treatment4040 8040 4021 Reverse osmosis Membrane for Industrial Waste Water treatment
CategoriesIndustrial Reverse Osmosis Membrane
AlbumView larger image
BrandKTMT
Stabilized Salt Rejection %99%
Minimum salt rejection %98%
Testing pressure150pai(1.03Mpa)
Max Feed water temperature:45℃
Maximum operating pressure600psi(2.07Mpa)
Maximum pressure drop15psi(0.1Mpa)
FOB portTianjin, China.
Terms of PaymentL/C, Western Union, T/T, Paypal
Update Time2019-07-18
Detail Information
4040 8040 4021 Reverse osmosis Membrane for Industrial Waste Water treatment

Introduction:


RO, for Reverse Osmosis in English, is to spend hundreds of millions of dollars and after years of carefully developed in high-tech water procession technology. Generally, the reverse osmosis membrane is 6"/152mm

in diameter, and there is no central support frame,open end, filtering way of fluid flow from the inside out. Filter design of large diameter increases the effective filter area can greatly reduce the amount of filter and decrease the size of the shell. Because of its large flow, filtering long life, in many applications can reduce investment and manpower cost

RO membrane commonly specifications in KTMT

Dimension

Length

20''(528mm), 40''(1022mm) , 60''(1538mm)

Micron ratings

1um,4.5um,6um,10um,20um,40um,70um,100um

OD

6'' (152mm)

Capability

Stabilized Salt Rejection %

98

99

99

Minimum salt rejection %

98

99

99

Average Permeate flow GPD(m³/d)

2800(10.6)

2400(9.1)

1900(7.2)

Active Membrane Area ft2(m2)

85(7.9)

85(7.9)

85(7.9)

Testing Conditions

Testing pressure

150pai(1.03Mpa)

Temperature of Testing Solution

25°C

Concentration of Testing Solution (NaCl)

1500ppm

ph value of Test solution

8

Recovery of Single membrane element

0

Extreme conditions of usage

Maximum operating pressure

600psi(2.07Mpa)

Maximum temperature water inflow

45°C

Maximum water inflow SDI

5

Influent concentration of free chlorine

<0.1ppm

Influent pH range with continuous operation

3~10

Water ph range of chemical cleaning

2~12

Maximum pressure drop

15psi(0.1Mpa)

Features:
1. The gradient structure of aperture
2. The filtered water, a filter traffic up to 110 m after/h
3. The maximum filtering system size can be reduced by 50%
4. Can provide 20 ', 40 ', 'and 60 "the length of the filter
5. From the inside out flowing direction to ensure that all impurities trapped inside the filter element

Application:
1. RO security filter, sea water desalination pretreatment
2. Power plant of condensed water filtration
3. The biological pharmaceutical industry apis, solvent, water filtration
4. Bottled water, sugar, cooking oil and so on
5. Paint, coating, oil chemical industry
6. Microelectronics, film, fiber and resin
