Titanium Sintered Filter Cartridges for water treatment

Titanium Sintered Filter Cartridges for water treatment

Titanium Sintered Filter Cartridges for water treatment
Titanium Sintered Filter Cartridges for water treatmentTitanium Sintered Filter Cartridges for water treatmentTitanium Sintered Filter Cartridges for water treatmentTitanium Sintered Filter Cartridges for water treatmentTitanium Sintered Filter Cartridges for water treatment
CategoriesStainless steel filtration
AlbumView larger image
BrandKTMT
Filter mediumhigh purity titanium
Relative filtration pore size0.22~80 µm
Length10
Sealing materialSilastic, NBR, EPDM, Viton
Porosity28~50%
Diameter60.0 mm
Temperature tolerance≤300°C (wet)
Max. working pressure0.6 MPa
FOB portTianjin, China.
Terms of PaymentL/C, Western Union, T/T, Paypal
Update Time2018-11-22
Detail Information



1. Product Description


The filtration media of Titanium Sintered filter cartridge is high purity titanium as the material. It is made by sintering in high temperature and vacuum, with unique properties.



2. Specifications


 Filter medium

 high purity titanium

 Relative filtration pore size

 0.22~80 µm

 Length

 10", 20", 30", 40”

 Sealing material

 Silastic, NBR, EPDM, Viton

 Porosity

 28~50%

 Diameter

 60.0 mm

 Temperature tolerance

 ≤300°C (wet)

 Max. working pressure

 0.6 MPa



Pure water flow rate reference table: the initial value of 10’’cartridge L/H

(P=0.2 MPa, 1cP, 25°C)


Micro rating(um)

0.2

0.45

1

2

3

5

10

20

30

50

80

Flow rate(L/H)

180

200

250

280

300

350

500

800

1000

1500

1600


3. Features


High temperature resistant and used many times

washable for re-use and maximum economy

A large number of pores, uniform pore, small resistance, great permeability.

With excellent high and low temperature resistance, long service life, easy regeneration.



4. Applications


-Widely used in various media of the separation and filtration of gas or liquid.

- Suitable for filtering in the media of strong acid, strong alkali and high temperature.
