FMS Fiberglass Composite Filter Bags

FMS Fiberglass Composite Filter Bags

FMS Fiberglass Composite Filter Bags
CategoriesDust Filter Bag
AlbumView larger image
BrandKTMT
Fiber MaterialsFiberglass + Aramid, Fiberglass + PI, Fiberglass +
Standard FinishesHeat Set, Singed, Glazed, PTFE membrane
Weight oz/yd² (g/m2)23.60-26.55 (800-900)
Thickness Inch (mm)0.087-0.11 (2.2-2.8)
Max. Operating Temperature oF (oC)500 (260)
Air Permeability20-50 (10-25)
FOB portTianjin, China.
Terms of PaymentL/C, Western Union, T/T, Paypal
Update Time2019-09-23
Detail Information

FMS Fiberglass Composite Filter Bags

Introduction:

Using the finest fiber material possible in the market and high-speed modern needling equipment, we manufacture our own filter media for our dust filter bags guaranteeing the highest quality, reliability, and consistency
A wide range of surface finishes and chemical treatments that aid in the collection and release of the dust from the bags
Ultrasonic welded seam for increased efficiency and reinforced mechanical strength
Our laboratories are equipped with sophisticated testing equipment used to analyze and evaluate all aspects of your process and application
Custom fabricated bag designs to meet the unique needs of your bag house installation



Specification:



Fiber Materials

 Fiberglass + Aramid, Fiberglass + PI, Fiberglass + PPS

Standard Finishes
(Special surface treatments available)

Heat Set, Singed, Glazed, PTFE membrane

Weight
oz/yd² (g/m2)

23.60-26.55 (800-900)


Thickness
   Inch (mm)

0.087-0.11 (2.2-2.8)

Air Permeability
 CFM@ ½" W.G125PA
 (m³/m².min@200PA )

20-50 (10-25)

  Tensile Strength
 lb/in (N/5CM)

Warp MD

274 (2400)

Weft CD

228 (2000)

Tensile Elongation (%)

Warp MD

≤15

Weft CD

≤10

Thermal Shrinkage (%) at max continuous temp.

Warp MD

≤1

Weft CD

≤1.5

Max. Operating Temperature  oF (oC)

Continuous

500 (260)

Surge

536 (280)

The data are based on laboratory conditions.
Testing based on specific operating conditions of each installation is recommended.



Media Feature:



---High temperature and corrosion resistance

---Good high temperature resistance filter fabrics

---Increase the filter surface

---Increase the fiber cohesion

---Filter efficiency will superior than woven filter fabrics



Application:



>Metallurgical plant

>Chemical plant

>Coal fired boiler

>Incinerator

>Cement plant

>Custom OEM Applications
