Polyester (PE) Dust Filter Bags

Polyester (PE) Dust Filter Bags

Polyester (PE) Dust Filter Bags
Polyester (PE) Dust Filter BagsPolyester (PE) Dust Filter BagsPolyester (PE) Dust Filter Bags
CategoriesDust Filter Bag
AlbumView larger image
BrandKTMT
Fiber MaterialsPE-Polyester
ScrimPolyester
Standard Finish Options (Special surface treatmentHeat set, singed, glazed, oil-repellent and waterproof, PTFE membrane
Weight oz/yd² (g/m2)11.80-17.70 (400-600)
Thickness Inch (mm)0.063-0.091 (1.6-2.3)
FOB portTianjin, China.
Terms of PaymentL/C, Western Union, T/T, Paypal
Update Time2019-07-18
Detail Information

Introduction:

Using the finest fiber material possible in the market and high-speed modern needling equipment, we manufacture our own filter media for our dust filter bags guaranteeing the highest quality, reliability, and consistency
A wide range of surface finishes and chemical treatments that aid in the collection and release of the dust from the bags
Ultrasonic welded seam for increased efficiency and reinforced mechanical strength
Our laboratories are equipped with sophisticated testing equipment used to analyze and evaluate all aspects of your process and application
Custom fabricated bag designs to meet the unique needs of your bag house installation

Specification:

Fiber Materials

PE-Polyester

Scrim

Polyester

Standard Finish Options (Special surface treatments available)

Heat set, singed, glazed, oil-repellent and waterproof, PTFE membrane

Weight oz/yd² (g/m2)

11.80-17.70 (400-600)

Thickness
   Inch (mm)

0.063-0.091 (1.6-2.3)

Air Permeability
 CFM@ ½" W.G125PA
 (m³/m².min@200PA )

25-33 (12-16)

  Tensile Strength lb/in (N/5CM)

Warp MD

126 (1100)

Weft CD

148 (1300)

Tensile Elongation (%)

Warp MD

≤25

Weft CD

≤40

Thermal Shrinkage (%) at max continuous temp.

Warp MD

≤1

Weft CD

≤1.5

Max. Operating Temperature  oF (oC)

Continuous

265 (130)

Surge

302 (150)

The data are based on laboratory conditions.
Testing based on specific operating conditions of each installation is recommended.



Media Feature:

-Most versatile, cost effective, and widely used

-With good air permeability and also can be adjusted by customers' specific request

-With high tensile strength and low tensile elongation

-Provides an economical combination of good resistance to chemicals and excellent abrasion resistance.

-Good for dry heat applications and superior to other synthetics with the exception of Nomex (Aramid) and PFTE (Teflon) in this matter.

-Good choice for moist heat and subject to hydrolytic degradation under certain circumstances

-Good resistance to most mineral and organic acids except high concentration of nitric, sulfuric, and carbolic acids

-Good resistance to weak alkalis and moderate resistance to strong alkalis at low temperature.

-Not recommend for high concentration of strong alkalis at high temperatures.

Continuous operating temperature 265oF (130°C)



Application:

Power Generation

Powder Coating

Paper, Pulp & Woodworking

Paints & Pigments

Cement, Mining & Rock Products

Asphalt & Aggregate

Chemicals & Pharmaceuticals

Metals & Foundry

Food & Beverages

Custom OEM Applications
