Oval Air Filter Cartridge

Oval Air Filter Cartridge

Oval Air Filter Cartridge
Oval Air Filter CartridgeOval Air Filter CartridgeOval Air Filter CartridgeOval Air Filter CartridgeOval Air Filter Cartridge
CategoriesAir Filter Cartridge
AlbumView larger image
BrandKTMT
ShapeOval-shaped
Major axis365-280mm
Minor axis288-203mm
AdvantagesReduced filter disposal cost
ItemOval Air Filter Cartridge
FOB portTianjin, China.
Terms of PaymentL/C, Western Union, T/T, Paypal
Update Time2019-07-18
Detail Information
Oval Air Filter Cartridge

Product Features:


It provides up to 25 percent more filtration air flow than other same-sized cartridge.
Shorter and stiffer filter pleats help minimize dust entrapment simplify filter cleaning. By reducing the height of the pleats from the standard 2inches to 1.5inches, the pleat wall is less likely to collapse or bend, which can encapsulate dust and prevent it's expulsion. Meanwhile cost was reduced.
Oval-shaped cartridge filters have fewer areas of high velocity, resulting in a lower potentially for media abrasion and increased filter life.


Specification:


Model

Major axis

Minor axis

Length

Filtration surface(m2)

KTMT/O3266

365-280mm

288-203mm

660mm

18m2

KTMT/O3275

365-280mm

288-203mm

750mm

20m2

KTMT/O3288

365-280mm

288-203mm

880mm

22m2

KTMT/03290

365-280mm

288-203mm

915mm

23m2



Advantages :
Lower initial cost per cubic foot of air per minute (cfm)
• Higher efficiency—cleaner air
• Lower pressure drop—greater energy savings
• Fewer filter changeouts
Reduced filter disposal cost
• Easy system setup
• Less maintenance

The innovation of shorter and stiffer filter pleats helps minimize dust entrapment and simplify filter cleaning. By reducing the height of the filter pleats from the standard 2 inches to 1.5 inches, the pleat wall is less likely to collapse or bend, which can encapsulate dust and prevent its expulsion.
