Spun Bonded Polyester Air Filter Cartridge with imported Media

Spun Bonded Polyester Air Filter Cartridge with imported Media

Spun Bonded Polyester Air Filter Cartridge with imported Media
Spun Bonded Polyester Air Filter Cartridge with imported MediaSpun Bonded Polyester Air Filter Cartridge with imported MediaSpun Bonded Polyester Air Filter Cartridge with imported Media
CategoriesAir Filter Cartridge
AlbumView larger image
BrandKTMT
Material:polyester and cellulose
gasket:Specialty chlorine rubber gasket
Operating temperature:≤135℃
Top cap:Galvanized
FOB portTianjin, China
Terms of PaymentL/C, Western Union, T/T, Paypal
Update Time2019-03-27
Detail Information

Spun Bonded Polyester Air Filter Cartridge with imported Media

Specification


Cartridge Model

Top Cap OD mm

Top Cap ID mm

Bottom Cap OD mm

Bolt Hole mm

Height mm

Filtration Surface

Efficiency
 (10%)

KTMT/P 3266

Φ324

φ213

Φ324

φ14

660

9.4

≥99.95

KTMT/P 3275

Φ324

φ213

Φ324

φ14

750

10.6

≥99.95

KTMT/P 32100

Φ324

φ213

Φ324

φ14

1000

14.2

≥99.95

KTMT/P 3566

Φ352

φ241

Φ352

φ16

660

10

≥99.95

KTMT/P 3575

Φ352

φ241

Φ352

φ16

750

11.3

≥99.95

KTMT/P 35100

Φ352

φ241

Φ352

φ16

100

15.1

≥99.95



Cartridge's length can be made as per your special requirements, any inquiry , please feel free to contact us



Features:

1,Imported long fiber polyester filter material with tight pore structure.

2, Excellent moisture resistance and dust release properties,High-wearing feature can improve the airflow.

3, Durable and rigid material, washable Greater withstanding performance to pulse jet than traditional materials.

5)Galvanized Top cap & inner frame ,rust resistance

6) Specialty chlorine rubber gasket to ensure airtight sealing.

7) Operating temperature ≤135



Application:

Suitable for filtration of the fine dust in plastic , Spray powder , sand blast , pigment and wood industries.



Filter media /Optional after-treatment

Description

Specification

Chemical Properties

No

Material

Post-processing

Weight g/

Thickness  mm

Max.
Temp

Permeability

Oil, water proof

hydrolysis resistance

Acid resistance

Alkali resistance

1

20%polyester +80% cellulose

130

0.64

80

**

*

*

*

*

2

15% polyester+85% cellulose

124

0.7

80

**

*

*

*

*

3

100% cellulose

118

0.79

80

**

-

-

*

*

4

15%polyester +85% cellulose

Nano Flame Retardant

138

0.79

80

***

**

*

*

*

5

15%polyester +85% cellulose

Nano

132

0.84

80

***

**

*

*

*

6

100% polyester

260

0..62

130

**

**

*

**

*

7

100% polyester

Anti-static

260

0..61

130

**

**

-

**

*

8

100% polyester

Flame retardant

260

0.61

130

**

**

**

**

*

9

100% polyester

Oil,water proof

260

0.61

130

***

***

***

**

*

10

100% polyester

PTFE membrane

240

0.6

130

*

-

***

**

**

260

0.68

135

*

-

***

**

**

270

0.83

135

*

-

***

**

**

11

100% polyester

PTFE membrane flame retardant

260

0.62

130

*

_

***

**

**

12

100% polyester

Anti-static
PTFE membrane

260

1.01

135

*

-

***

**

**

13

100% polyester

New PTFE membrane

135

0.58

110

*

-

***

**

**

Note : - No , * ordinary , ** good , *** very good
