Size2 PE filter bag for liquid filtration

Size2 PE filter bag for liquid filtration

Size2 PE filter bag for liquid filtration
Size2 PE filter bag for liquid filtrationSize2 PE filter bag for liquid filtrationSize2 PE filter bag for liquid filtrationSize2 PE filter bag for liquid filtrationSize2 PE filter bag for liquid filtration
CategoriesLiquid filter Bag
AlbumView larger image
BrandKTMT
Standard Sizeφ180x820mm(φ7
Filter Rating1μm,2μm,5μm,10μm,15μm,25μm,etc
Ring ModelSS316,SS304,plastic,Zinc Coated
MediumMilk,juice,ink,chemical,oil,etc
SeamWelded, Sewing,Welded top and Sewing Bottom, Sewing top and Welded Bottom
Effective filtration areavarious specifications
Features100% no leak,harmless,acid proof,alkali-resisting,etc
FOB portTianjin, China
Terms of PaymentL/C, Western Union, T/T, Paypal
Update Time2019-07-18
Detail Information
Size 2 PE Liquid Filter Bag

Introduction:

high quality filter bags are made of various materials which provide consistent filtration of liquid in a lot of applications .The filter felt offer efficient depth filtering at increased flow rates,various optional surface treatment are valid to reduce fiber migration and enhance filtration performance. The collars and top rings ensure general compatibility with most commercial bag filter housings in the market.

The connection for filter felt and top ring could be sewing or welded, suitable for different housings and purposes. Filter bags extended lifetime without media migration or bypass. Customized bag filters are appropriate for different requests in many industrial fields

Specification:

Raw Material

KTMT/USA

Efficient

99.9%

Standard Size

φ180x820mm(φ7’’x32’’)/OEM Welcomed

Filter Rating

1μm,2μm,5μm,10μm,15μm,25μm,etc

Ring Model

SS316,SS304,plastic,Zinc Coated

Features

100% no leak,harmless,acid proof,alkali-resisting,etc

Lifetime

5years

Warranty

12months

Working Time

7x24hours

Medium

Milk,juice,ink,chemical,oil,etc

Max.temperature

160

Treatment

POXL,PEXL,PTFE filmed,multi-layer, oil absorption,etc

Processing Way

Sewing/weld

Application

Food,chemical,power,oil,gas,medicine,machinery,textile,etc



Features:

- High particles holding capacity and large flow rate at low pressure drops

- Kinds of international and customized sizes fit most industry bag housings

- Low cost filter bags provide precision filtration, exceptional strength and longer service life

- Exquisite workmanship and complete quality management system make bag filters have consistence excellent performance

- Polypropylene, Polyester, Nylon and others material of filter felt with O-Rings offer for a lot of choices for application and operating temperatures



Item No#

Diameter(Inch)

 Length(Inch)

 mm

 1#

 7″

 17″

 180X420

 2#

 7″

 32″

 180X820

 3#

 4″

 9″

 100X230

 4#

 4"

 16″

 100X410

 5#

 6"

 21″

 152x520



Applications

--Chemical Industry: plastics industry,dry,paints,packing,tonner,etc.

--Minerals Industry: cement industry,coal mill,dryer system

--Metal Industry: iron and steel industry,coal-fired power,etc.

--Power generation and incineration: ferro alloy,Coal-fires power boilers,incinerator etc.
